Kaggle Digits Recognition

Jan 5, 2016

On my test post, we’ll solve Kaggle’s Digit Recognizer competition using python’s machine learning library sklearn. It a really simple problem and used as a starting point (along with the Titanic one) Kaggle competitions.

Exploring the data

import numpy as np

X =  np.genfromtxt('train.csv',dtype='int_',
                   delimiter=',', skip_header=1)
x_test =  np.genfromtxt('test.csv',dtype='int_',
                        delimiter=',', skip_header=1)
x_train = X[:,1:]
y_train = X[:,0]

Each row in the x_train and x_test data is a 28x28 pixels image with a total of 784 pixels. Therefore, we will write a simple function takes randomly selected rows, reshapes them into 28x28 matrices and display them using matplotlib.image.mpimg.

import matplotlib.pyplot as plt
%matplotlib inline

def display(n):
    for i in range(1,(n**2)+1):
        plt.subplot(n,n,i)
        plt.axis('off')
        pic = np.reshape(x_train[np.random.randint(1,42000)],(28,28))
        imgplot = plt.imshow(pic, cmap='Greys')
display(5)

Training the data

Logistic regression

from sklearn.linear_model import LogisticRegressionCV
model_log = LogisticRegressionCV(multi_class='multinomial')
model_log.fit(x_train, y_train)

Random forests

from sklearn.ensemble import RandomForestClassifier
model_rf = RandomForestClassifier(1000)
model_rf = ran.fit(x_train,y_train)

Neural Networks

import import tensorflow.contrib.learn as skflow
#Tensorflow library only accept numbers with type float
x_train = x_train.astype('float32')
y_train = y_train.astype('float32')
x_test = x_test.astype('float32')
model_nn = skflow.TensorFlowDNNClassifier(hidden_units=[100,50], n_classes=10, steps=100000)
model_nn.fit(x_train, y_train)

Now let’s check the accuracy of the training data.

print 'Logistic regression', model_log.score(x_train, y_train)
print 'Random forests', model_rf.score(x_train, y_train)
print 'Neural networks', model_nn.score(x_train, y_train)

prints: Logistic regression 0.941357142857 Random forests 1.0 Neural networks 0.99328571428571433

Submitting the data

We’re gonna do the same thing with but with the x_test data and do some data cleaning for submission.

def submit(model,x_test, name):
    # predict y using the test set
    y_test = model.predict(x_test)
    # kaggles requires the submission to include an index column
    index = np.arange(1,len(x_test)+1, dtype=int)
    # merging the y_test and index columns
    y_test = np.column_stack((index,y_test))
    # convert to pandas dataframe
    y_test = pd.DataFrame(y_test)
    # headers required for the submission
    y_test.columns = ['ImageId','Label']
    # write the data to csv file in the directory
    y_test = y_test.astype('int')
    y_test.to_csv("".join([name,'.csv']), index=False)

submit(model_log,x_test,'model_log')
submit(model_rf,x_test,'model_rf')
submit(model_nn,x_test,'model_nn')

Results

Model	Test Accuracy Score
Logistic Regression	0.91771
Random Forests	0.96800
Neural Networks	0.94900
